FRAME PARTS

Illus.

No.

Part No.

Description

1

Frame, Uprights

W10567496 Left Hand

W10567565 Right Hand

2

Block

W10567500 Black

W10567499 White

3

W10567501 Latch

4

Brace, Upper

W10567556 Black

W10567505 White

5

W10567502 Block, Coupling

6

W10567574 Nut, Leveling Leg

7

W10567573 Leg, Leveling

8

W10567653 Valve, Fill

9

W10567652 Clamp

10

W10567572 Brace, Lower

11

W10567576 Brace, Lower Rear

12

W10567566 Cover, Terminal Box

13

W10567567 Box, Terminal

01/007/2013

9

Part No. W10571026 Rev. A
