Operation 4‐31 MN2408
Figure 4‐17 Main Menu Loop Parameters
Parameter Setting Range
System Voltage (Line To Line) XXXXX VAC 120-15000V AC
System Frequency 50Hz/60Hz Toggle Between 50/60 Hz
System Phases 1 Phase/3 Phase Toggle Between 1 & 3 Phase
Neutral Connected Toggle Between Yes/No
Voltage Sensing Voltage Sensing Pt Ratio
Ratio XXX Enter Number 1-208 (1=Direct)
Current Sensing Current Sensing Ct Ratio
Ratio XXX Enter Number 1-999 (1=Direct)
Temperature Scale Deg C/Deg F Toggle Between Deg C/Deg F
Pressure Scale PSI/KPA Toggle Between Psi/Kpa
Start Delay XXX Seconds 0-999 Seconds
Crank Time XX Seconds 0-99 Seconds
Rest Time XX Seconds 0-99 Seconds
Starter Re-engage Delay XX Seconds 0-99 Seconds 0=Disabled
Number Of Cranks XX Cranks 0-99 Times 0=Continuous
Bypass Delay XX Seconds 0-99 Seconds
Cool down Delay XX Seconds 0-9999 Seconds
Nominal RPM XXXX RPM 0-4000RPM
Flywheel Teeth (Engine Speed
Sensing, Magnetic Pick Up XXX Teeth 0-999 Teeth
Crank Disconnect XX % 0-100%
Overspeed XX % 100-150%
Overspeed Transient X.X Seconds 0.0-9.9 Seconds
Run Output Fail Safe Yes/No Toggle Between Yes/No
Loss Of Speed Signal Shutdown Alarm/Shutdown Toggle Between Alarm/Shutdown
Common Fail For Not In Auto Yes/No Toggle Between Yes/No
Horn For Not In Auto Toggle Between Yes/No
Prog Output #1 Common Fail (Factory setting)
Prog Output #2 Common Fail (Factory setting)
Prog Output #3 Common Fail (Factory setting)
Prog Output #4 Common Fail (Factory setting)
Prog Output #5 Common Fail (Factory setting)
Prog Output #6 Common Fail (Factory setting)
Warm-up Delay 0-99 Seconds
Neutral Delay 0-99 Seconds
Return Delay 0-999 Seconds
Reset Run Hours Access by Master Password Only
Yes/No Toggle Between Yes/No
