REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
202400
K Included in Engine Gasket Set--Ref. No. 358.
D
Included in Carburetor Overhaul Kit--Ref. No. 121A.
∆ Included in Valve Gasket Set--Ref. No. 1095.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6591--19 Assemblies include all parts shown in frames. 10/07/2008
19
957 792647 Cap--Fuel Tank
(Plastic)
958 698180 Valve--Fuel Shut Off
(Plastic)
967 491435S Filter--Pre Cleaner
967A 695303 Filter--Pre Cleaner
Used on Type No(s).
0114, 0124, 0125,
0135, 0166, 0175,
0181, 0183, 0185,
0207, 0212, 0434.
968 790959 Cover--Air Cleaner
968A 692321 Cover--Air Cleaner
Used on Type No(s).
0167, 0168, 0210.
968B 695301 Cover--Air Cleaner
Used on Type No(s).
0114, 0124, 0125,
0135, 0166, 0175,
0181, 0183, 0185,
0207, 0434.
968C 791930 Cover--Air Cleaner
971 695181 Screw
(Air Cleaner Base to
Carburetor)
Used on Type No(s).
0114, 0124, 0125,
0135, 0166, 0175,
0181, 0183, 0185,
0207, 0434.
972A 694260 Tank--Fuel
(Plastic)
------------ Note ------------
697779 Tank--Fuel
(Plastic)
Used on Type No(s).
0135.
975A 696138 Bowl--Float
990 691959 Key Set
Used on Type No(s).
0041, 0127, 0140.
990A 695756 Key Set
994 392390 Arrestor--Spark
Used on Type No(s).
0114, 0124, 0125,
0132, 0142, 0147.
1005 694684 Fan--Flywheel
1006 690452 Retainer--Fan
1022 K∆690971 Gasket--Rocker Cover
1023 697691 Cover--Rocker
1026 695177 Rod--Push
1029 690972 Arm--Rocker
1036 Label--Emissions
(Available From A
Briggs & Stratton
Authorized Dealer)
1046 691337 Plug--Blower Housing
Used on Type No(s).
0140, 0180.
1051 691265 Ring--Retaining
1052A 791159 Sensor--Oil
1058 277040 Manual--Operator’s
------------ Note ------------
MS3780 Manual--
Operator’s
Used on Type No(s).
0033, 0063, 0105,
0118, 0119, 0121,
0122, 0123, 0124,
0125, 0128, 0135,
0136, 0149, 0150,
0151, 0152, 0154,
0157, 0158, 0159,
0161, 0167, 0171,
0178, 0194, 0210.
MS3790 Manual--
Operator’s
Used on Type No(s).
0157, 0158.
1070 691058 Screw
(Flywheel Fan)
1090 691293 Retainer--Brush
1095 695440 Gasket Set--Valve
1100 791959 Pivot--Rocker Arm
1119 691183 Screw
(Alternator)
1127A 695407 Screw
(Float Bowl)
1138 694255 Nut
(Control Bracket)
1177 710090 Nut
(Muffler)
1194 691876 Seal--O Ring
(Plug)
1210 498144 Pulley/Spring
Assembly
(Pulley)
1211 498144 Pulley/Spring
Assembly
(Spring)
1230 791754 Stud
(Control Bracket)
1319 794467 Label--Warning
1404 696757 Nut
(Control Cover)
