REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
202400
K
Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121A.
∆ Included in Valve Gasket Set--Ref. No. 1095.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6591--14 Assemblies include all parts shown in frames. 10/07/2008
14
21 281658S Cap--Oil Fill
22 695174 Screw
(Crankcase
Cover/Sump)
23 794814 Flywheel
------------ Note ------------
695485 Flywheel
Used on Type No(s).
0033, 0041, 0111,
0125, 0127, 0133,
0135, 0139, 0140,
0154, 0161, 0180,
0181, 0183, 0193,
0197, 0203, 0204,
0209, 0211.
24 222698S Key--Flywheel
25 792117 Piston Assembly
(Standard)
------------ Note ------------
792144 Piston
Assembly
(.020” Oversize)
26 792026 Ring Set
(Standard)
(Used After Code Date
05081000).
------------ Note ------------
694004 Ring Set
(Used Before Code
Date 05081100).
792073 Ring Set
(.020” Oversize)
(Used After Code Date
05081000).
694008 Ring Set
(.020” Oversize)
(Used Before Code
Date 05081100).
27 690975 Lock--Piston Pin
28 696581 Pin--Piston
29 694691 Rod--Connecting
30 694692 Dipper--Connecting
Rod
32 690976 Screw
(Connecting Rod)
33 499596 Valve--Exhaust
34 792200 Valve--Intake
35 694865 Spring--Valve
(Intake)
36 694865 Spring--Valve
(Exhaust)
37 790730 Guard--Flywheel
37A 696701 Guard--Flywheel
Used on Type No(s).
0135, 0142.
42 499586 Keeper--Valve
45 690977 Tappet--Valve
46 790958 Camshaft
51 694874 Gasket--Intake
51A K
D ∆
694875 Gasket--Intake
53 K
D ∆
694869 Stud
(Carburetor)
53A 695433 Stud
(Carburetor)
Used on Type No(s).
0114, 0124, 0125,
0135, 0166, 0175,
0181, 0183, 0185,
0207, 0212, 0434.
55 695288 Housing--Rewind
Starter
58 693389 Rope--Starter
(Cut To Required
Length)
59 805957 Insert--Grip
60 490652 Grip--Starter Rope
65 690837 Screw
(Rewind Starter)
------------ Note ------------
690759 Screw
(Rewind Starter)
Used on Type No(s).
0033, 0041, 0111,
0114, 0121, 0122,
0125, 0127, 0128,
0133, 0135, 0136,
0139, 0140, 0151,
0154, 0157, 0158,
0161, 0167, 0168,
0177, 0180, 0181,
0183, 0185, 0193,
0197, 0203, 0204,
0205, 0207, 0209,
0210, 0211, 0212.
697725 Screw
(Rewind Starter)
Used on Type No(s).
0142, 0147.
78 690372 Screw
78A 695724 Screw
(Flywheel Guard)
Used on Type No(s).
0135, 0142.
79 690614 Case--Gear Reduction
(Used Before Code
Date 07021600).
Used on Type No(s).
0049, 0128, 0193,
0209.
79A 793590 Case--Gear Reduction
(Used After Code Date
07021500).
Used on Type No(s).
0049, 0128, 0193,
0209, 0212.
80 691603 Gasket--Gear Case
(Used Before Code
Date 07021600).
Used on Type No(s).
0049, 0128, 0193,
0209.
80A 793588 Gasket--Gear Case
(Used After Code Date
07021500).
Used on Type No(s).
0049, 0128, 0193,
0209, 0212.
81 695400 Lock--Muffler Screw
82 690287 Screw
(Gear Reduction Case)
(Used Before Code
Date 07021600).
Used on Type No(s).
0049, 0128, 0193,
0209.
82A 792753 Screw
(Gear Reduction Case)
(Used After Code Date
07021500).
Used on Type No(s).
0049, 0128, 0193,
0209, 0212.
83 690387 Shaft--Auxiliary Drive
84 691121 Plug--Breather
85 691076 Screw
(Gear Cover to Gear
Reduction Case)
86 690613 Cover--Gear
(Used Before Code
Date 07021600).
Used on Type No(s).
0049, 0128, 0193,
0209.
86A 793591 Cover--Gear
(Used After Code Date
07021500).
Used on Type No(s).
0049, 0128, 0193,
0209, 0212.
