Behringer SINGLE DIAPHRAGM CONDENSER MICROPHONE B-1 - Manual (Page 4)

4 SINGLE DIAPHRAGM CONDENSER MICROPHONE B-1 User Manual
Specifications 5.
Transducer type condenser, 1" single diaphragm
Operating principle pressure gradient
Polar pattern cardioid
Connection gold-plated balanced XLR connector
Open circuit voltage at 1 kHz -34 +/-2 dBV (0 dBV = 1 V/Pa)
Open circuit sensitivity 20 mV/Pa
Frequency range 20 Hz - 20 kHz
Level attenuation -10 dB (switchable)
Low-Cut filter 6 dB/Octave at 75 Hz (switchable)
Max. SPL (1% THD @ 1 kHz) 138 dB (0 dB), 148 dB (-10 dB)
Equivalent SPL (IEC 268-4) 13 dB-A
Signal-to-noise ratio re 1 Pa 81 dB A-weighted
Nominal impedance 50 Ω
Load impedance > 1 kΩ
Mains Voltage/Fuse
Supply voltage +48 V
Supply current 3 mA
Physical/Weight
Dimensions 0: 58 mm, length: 174 mm
Weight 0,461 kg
