SECTION I
INTRODUCTION AND DESCRIPTION
INTRODUCTION
We are pleased to have you as a Bush Hog customer. Your Bush Hog
Trail Series utility vehicle has been carefully designed to give maxi-
mum service with minimum down time. This manual is provided to give
you the necessary operating and maintenance instructions for keep-
ing your vehicle in top operating condition. Please read this manual
thoroughly. Understand what each control is for and how to use it.
Observe all safety precautions decaled on the machine and noted
throughout the manual for safe operation of the vehicle. If any assis-
tance or additional information is needed, contact your authorized
Bush Hog dealer.
DESCRIPTION (Trail Hunter shown on next page)
1. Occupant Protection
Structure (O.P.S.)
2. Hand hold
3. Gear Selector
4. Steering wheel
5. Seat
6. Seat Belt
7. Fuel Tank Cap
8. Battery (Under Hood)
9. Headlights
10. Front Bumper/
Brush Guard
11. Power Winch (Optional)
12. Cargo Light (Optional)
13. Cargo Box
14. Hitch Receiver
15. Winch Wiring Pigtail
16. Cup Holder
17. Ignition Key
18. Fuel Gauge
17. Ignition Key
18. Fuel Gauge
19. Hour Meter
20. Choke Knob
21. Power Bed Lift Switch
(Optional)
22. Neutral Light
23. 4-Wheel Drive Switch
and Light
24. Winch Switch (Optional)
25. Driving Light Switch
26. Cargo Bed Light Switch
27. Parking Brake Light
28. Oil Pressure Light
29. DC Power Outlet
30. Parking Brake
31. Brake Pedal
32. Throttle Pedal
33. Tailgate Latch
34. Cargo Box Release Handle
