E-4
PART NAMES
FRONT / BACK
1 Main Unit Display (Ref.E-5)
2 Front Monitor
3 Main Unit
1
3
1 Air Outlet 6 Float
2 Handle (2 Locations) 7 Humidifying Tray
3 Sensor (Internal)
•Dust Sensor
•Temperture / Humidity Sensor
•Odour Sensor
(KC-A60EU•KC-A50EU ONLY)
8 Caster (4 Locations)
9 HEPA Filter (white)
10 Deodorizing Filter (black)
11 Back Panel (Pre-Filter)
12 Air Inlet
4 Water Tank 13 Power Cord / Plug
5 Humidifying Filter
1
2
3
4
5
7
2
8
9
10
11
6
13
(Shape of plug depends on country.)
12
INCLUDED
• Operation manual
• Slipper ×4
