Installation Instructions
Step 4: Secure appliance into
housing unit
Insert appliance into cabinet.
Note: The unit housing the appliance
must be appropriately fixed.
To secure appliance to housing unit
Note: Ensure that the appliance is
centrally located.
Take care not to damage the appliance
or cabinet.
There are 6 black no 8 x 25mm long
chipboard
screws
for
securing
appliance to cabinet.
■ Open the grill / top oven door,
and screw 2 screws through the
top corner holes in the front frame.
■ With the grill / top oven door still
open, screw 2 screws through the
holes in the front frame, located
under the grill compartment.
Close the grill / top oven door.
■ Open the main oven door, and
screw the remaining 2 screws
through the bottom corner holes in
the front frame.
Close the main oven door.
