Preparations
Others
Opreation
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
INDEX
A
Adjustment ------------------------------ 24-28
- Angle of fluorescent lamps ------ 19
- Brightness ---------------------------------------- 20
- Color ------------------------------------------------- 26
- Focus ------------------------------------------------- 20
- Outline ---------------------------------------------- 27
- Tone ------------------------------------------ 20, 25
- White balance ------------------------------ 25
- Zoom ---------------------------------------- 19, 37
B
Brightness adjustment ----------- 20
C
Camera head ----------------------- 15, 16
Change Pointer ---------------------------- 28
Cleaning ----------------------------------- 38, 39
- Main unit ----------------------------------------- 38
- Mouse ----------------------------------------------- 39
Color ------------------------------------------------------ 26
Connection ------------------- 13, 14, 17
- Ethernet -------------------------------------------- 14
- Monitor --------------------------------------------- 13
- Mouse ----------------------------------------------- 14
- PC ------------------------------------------------------- 14
- Power cable ----------------------------------- 17
- Projector ------------------------------------------- 13
- TV receiver -------------------------------------- 13
D
D-sub 15-pin connector --- 7, 13
E
Electronic zoom ---------------------------- 19
Ethernet ---------------------------------------------- 14
F
Fit ----------------------------------------------------------- 28
Fluorescent lamp ---- 12, 17, 38
Freeze ----------------------------------------- 20, 36
G
Gain ------------------------------------------------------- 24
I
Iris ----------------------------------------------------------- 27
L, M, N
Lights ---------------------------------------------------- 24
Mouse ------------------------------ 12, 14, 39
Network ----------------------------------- 14, 32
O
Opaque material ------------------------ 18
Over ------------------------------------------------------- 28
P
PC card ------------------------------------------------ 33
PC CARD slot -----------------------------5, 33
Pen function ------------------------------------ 36
Pointer ------------------------------------------------- 28
Projector --------------------------------------------- 13
R, S, T
RS-232C connector --------------7, 14
S-video output
connector -----------------------------7, 13
Sharpness ----------------------------------------- 27
Save to Card ----------------------------------- 28
Save to Server ------------------------------ 28
Slide-Show ----------------------------- 31, 36
SXGA ---------------------------------------------------- 28
Tone -------------------------------------------------6, 25
Transparent material -------------- 18
V, W, Z, X
Video output connector--- 7, 13
White balance ------------------------------- 25
Zoom ------------------------------------------ 19, 37
XGA ------------------------------------------------------- 28
INDEX
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
TROUBLESHOOTING
Symptoms
Power does not
go on.
No picture
is obtained.
The picture is not
clear.
The picture is not
fully displayed.
Pale or muddy colors.
Measures
• Check that the power cable is not disconnected from the AC outlet or the AC power input
receptacle of the unit. (☞ p.17)
• Check that the cables are firmly connected. (☞ pp.13, 14)
• Check that the cable is firmly connected to the appropriate receptacle of the equipment to
be used in combination. (☞ pp.13, 14)
• Check that the power switch is set to ON. (☞ p.18)
• Check that the fluorescent lamps are lit. (☞ pp.18, 24)
• Check that switching between the overhead and base lighting is correct. (☞ pp.18, 24)
• Check that the document is not completely white or black.
• When displaying the image of a PC card file, check that the file is not of a format that
cannot be read by this unit. (☞ p.33)
• Check that the lens cap is removed. (☞ p.16)
• Check the focus. Press the FOCUS 8 / 9 buttons to obtain proper focus. (☞ p.20)
• Check that the lens is placed correctly. (☞ p.15)
• Check that switching between SXGA and XGA is correct. (☞ p.29)
• Adjust "Gain" and "Color" using the menu. (☞ pp.24, 26)
• Try the TONE function by pressing the TONE button. (☞ p.6)
TROUBLESHOOTING
