(2) (3) (4) (1) (5)
7 6
Knowing your Router
7 6
Rear Panel
The following figure illustrates the rear panel of your Router.
1. PWR
Connect the included power supply to this inlet. Using the wrong
type of power adapter may cause damage to your Router.
2. LAN
The Ethernet ports are RJ45, 10/100 auto-negotiation. The ports
are labeled 1 through 4. These ports correspond to the numbered
LEDs on the front of the Router. Connect your network-enabled
computers or any networking devices to one of these ports.
3. USB
The USB client port connects your network-enabled computers
or any networking devices to the Router.
4. ADSL Line
This port is for connection to your ADSL line. Connect your ADSL
line to this port.
