Toshiba Satellite Pro A50-A User Manual
Page 43
Figure 3-6 The front of the computer with the display panel open
1
6
13
13
11
7
8
9
9
7
8
2
3
4
2
6
A
B
10
5
12
14
9
9
1. Wireless communication antennas
(not shown)*
8. eco indicator
2. Microphone*
9. Touch Pad control buttons
3. Web Camera LED*
10. Power button
4. Web Camera*
11. Keyboard
5. Display screen
12. Touch Pad
6. Display hinges
13. AccuPoint control button*
7. Touch Pad ON/OFF indicator*
14. AccuPoint *
* Provided with some models.
Product appearance depends on the model you purchased.
Wireless
communication
antennas
Some computers in this series are equipped with
the Wireless LAN/Bluetooth antennas.
Legal Footnote (Wireless LAN)
For more information regarding Wireless LAN, please refer to the
section.
User's Manual
3-9
