4
SERVICE CONNECTION
C
ELECTRICAL CONNECTION: Ø1 1/8" hole for electrical connection. Rating to be as specified on data plate.
DRAIN: 1"IPS to open floor drain. No solid connection. Use copper only, 24" length before open air gap opening (No bends or elbows).
GENERATOR WATER: 3/8" O.D. tubing at 25-50 PSI(170-345 kPa)
CONDENSING WATER: 3/8" O.D. tubing at 25-50 PSI(170-345 kPa)
WATER QUALITY STATEMENT
WATER QUALITY IS THE MAJOR FACTOR AFFECTING THE PERFORMANCE OF YOUR APPLIANCE. IF YOU ARE UNSURE OF WATER
QUALITY, CONSULT A LOCAL WATER TREATMENT SPECIALIST AND HAVE THE WATER ANALYZED. YOUR WATER SUPPLY MUST BE
TOTAL DISSOLVED SOLIDS
TOTAL ALKALINITY
SILICA
CHLORINE
pH FACTOR
WATER WHICH FAILS TO MEET THESE STANDARDS SHOULD BE TREATED BY INSTALLATION OF A WATER CONDITIONER.
FAILURE OR MALFUNCTION OF THIS APPLIANCE DUE TO POOR WATER QUALITY IS NOT COVERED UNDER WARRANTY.
LESS THAN 60 PPM
LESS THAN 20 PPM
LESS THAN 13 PPM
LESS THAN 1.5 PPM
7.0-8.5
WITHIN THESE GENERAL GUIDELINES:
ELECTRICAL CHARACTERISTICS
17 [432] 27.5 [698]
15
[3
81
] 24
[6
10
]
1.75 [45]
1.
75
[4
5]
3
[7
6]
1.13 [29]
SN
-3
E
SN
-5
E
1.
5
[3
8]
12
.5
[3
18
]
19
[4
83
]
20 [508]
OPTIONAL LEGS
15
.1
2
[3
84
]
4 [102]
21
.6
2
[5
49
]
SN
-5
E
SN
-3
E
1
[2
5]
23.5 [597] 2 [51]
1/2-NPT DELIME INLET
DIMENSIONS ARE IN INCHES [MM]
