Figure 3-6 The front of the computer with the display panel open
9
8
11
15
13
14
1
6
7
9
8
10
5
2 3 4
12
1. Wireless communication antennas
(not shown)* 9. Stereo speakers
2. Microphone 10. Keyboard
3. Web Camera LED* 11. Fingerprint Sensor*
4. Web Camera* 12. LCD Sensor switch (not shown)
5. Display screen 13. Touch Pad
6. TOSHIBA eco button* 14. Touch Pad control buttons
7. Power button 15. Touch Pad ON/OFF indicator
8. Display hinge
* Provided with some models.
Product appearance depends on the model you purchased.
Wireless
communication
antennas Some computers in this series are equipped with
the Wireless WAN/WiMAX antennas.
Legal Footnote (Wireless LAN)
For more information regarding Wireless LAN, please refer to the
Legal
Footnotes section.
Microphone The built-in microphone allows you to import and
record sounds for your application - please refer
to the
Sound System and Video mode section for
more information.
Web Camera LED The Web Camera LED glows when the Web
Camera is operating.
