Bissell 3108 - Manual (Page 7)

Cleaning with ready to use hose
1. Detach the hose from the hose port at the
bottom/back of the canister. Press the lock
button and pull the hose from the port. Insert
the crevice tool into the end of the hose.
2. To resume canister or upright cleaning,
remove crevice tool and store in crevice
tool clip. Reconnect hose to the hose port,
making sure it is locked fully in place.
Emptying the dirt cup
Your Easy Vac features a translucent plastic dirt
cup, so you can easily see when it needs to be
emptied. For best performance, empty when
debris reaches halfway up the cup.
1. Press the lock button down and forward
(away from the canister handle) while
lifting the upper portion of the dirt cup
away from the canister.
2. Grasp the filter frame and pull it straight
up from the dirt cup. Empty the dirt cup
and check for cleanliness and damage. You
may wash the cup with warm (not hot) water
and mild liquid dish soap. Rinse and dry
thoroughly before reattaching it.
3. If the surface of the filter looks dirty or
discolored, clean or replace it. To clean
the filter, remove any debris still clinging
to it. You may also wash the filter (#32047
Polyester Fiber only) by gently rinsing under
warm running water. Be sure the filter is
completely dry before replacing it in your
Easy Vac. Over time, it may be necessary to
purchase replacement filters.
4. Replace the filter in the dirt cup pushing
down tightly to ensure gasket is in place.
Place the small tab on the bottom of the cup
into the bottom of the canister cavity. Press
the upper portion of the cup until the lock
button snaps into place.
O
perations (continued)
7
