INSTALLATION
4
To install the Floppy Drive Kit, please follow below steps:
1. Unplug your computer.
2. Remove the cover from your computer. Refer to
your computer system manual for instructions.
3. If you are replacing a current floppy
drive, pay close attention to the
cables that are connected to
the floppy drive. You will
use the same cables to
connect your new
Belkin floppy drive.
4. Refer to your computer
system manual for
instructions regarding the
mounting of disk drives.
5. If your computer has an
available 3.5-inch drive bay,
insert the floppy disk drive directly into the drive bay, and
secure the drive using the six mounting screws provided.
6. If you need to mount the floppy drive into a 5.25-inch drive
bay, mount the floppy drive into the 5.25-inch drive bay
adapter as shown in Fig. 1.
7. Connect the power cable as shown in Fig. 1.
Fig. 1
