Installation
Note:
• Before finally installing the unit, connect the wiring temporarily, making sure it is all connected up properly,
and the unit and the system work properly.
• Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can
cause malfunction.
• Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the
vehicle.
• Install the unit where it does not get in the driver’s way and cannot injure the passenger if there is a sudden
stop, like an emergency stop.
Installing the Unit
1. Install the brackets to the bottom of the unit.
2. Install the unit to the vehicle.
Tapping screw (4
× 12 mm)
Drill a hole of 2–2.5 mm
Car mat or shassis
Bracket
Bind screw (4
× 5 mm)
54
Connecting the Units / Installation
