Appendix
Troubleshooting
➲ About troubleshooting other than description
below ➞ Appendix of the Operation Manual
Symptom Cause Action (See)
There’s no picture. The handbrake cord is not connected. Connect a handbrake cord, and apply the
handbrake.
The handbrake is not applied. Connect a handbrake cord, and apply the
handbrake.
The icon is
displayed, and
operation is not
possible.
The operation is prohibited for the disc. This operation is not possible.
The operation is not compatible with the
disc’s organization.
This operation is not possible.
The picture stops
(pauses) and the unit
cannot be operated.
Reading of data has become impossible
during playback.
After pressing 7 once, start playback once
more.
The picture is
stretched, the aspect is
incorrect.
The aspect setting is incorrect for the
display.
Select the appropriate setting for your
display. (Page 15)
Rear display picture
disappears.
• The source disc being listened to with the
product has been ejected.
• The disc without a video source is
playbacked.
• The REAR button was pressed and REAR
ON mode switched off.
• There was a problem with the rear display
or a faulty wiring connection, for example.
• Rear View is selected on the screen.
• When the gearstick is in [R], displays rear
view camera images. (When “NAVI” is
selected in REAR DISP menu.)
• Before ejecting the disc, switch the
source.
• Switch the source with a video source.
• Press the REAR button to turn REAR ON
mode on.
• Check the rear display and its connection.
• Select view mode other than Rear View.
• Select SOURCE in REAR DISP menu.(or
when you move the shift lever other than
[R] position, the screen will be returned to
the previous display.)
Nothing is displayed
and the touch panel
keys cannot use.
The setting for the rear view camera is
incorrect.
The gearstick was placed in [R] when the
rear view camera was not connected.
Connect a rear view camera correctly.
Press NAVI/AV button to return to the
source display and then select the correct
setting for CAMERA.
➲ About CAMERA setting ➞ Operation
Manual
LCD Panel knocking
against your vehicle’s
console or dashboard.
Incorrect setting of angle. Press ANGLE (+/–) to adjust the LCD
angle. Forcibly adjusting the LCD panel by
hand may damage it.
Video image appears
grainy.
This happens when videos are viewed in
CINEMA or ZOOM mode.
Select a different mode to view videos.
