Operating VirtualDJ Pro 7 using the
XDJ-AERO’s buttons
9
9
9
AUTO MIX
CROSS F.
CURVE
LOW
HI
SE
AR
CH
AUTO CUE
UTILITY
TIME
rekordbox
MIDI
USB
AUTO
BEAT LOOP
PHONO1/
DECK1
HEADPHONES
MASTER
LEVEL
LEVEL
MASTER
MASTER
MIXING
TRIM
HI
MID
LOW
FILTER
LEVEL
CUE
0
1
2
3
4
5
6
7
8
9
10
0
1
2
3
4
5
6
7
8
9
10
MASTER
LINE1
USB
STOP
MASTER
REC
5V 500mA
MASTER
TEMPO
SYNC
CH1
CH1
TRIM
HI
MID
LOW
FILTER
CH2
TEMPO
THRU
SHIFT
PHONES
CUE
PLAY/PAUSE
1
WPS
2
3
4
INFO
TOP
FX SELECT
TRANS
BA
NK
JOG
DR
UM
SAMPLE
LA
UNCH
FLANGER
ROLL
ECHO
LEVEL/DEPTH
BEAT
BACK
CH2
PHONO2/
DECK2
MIC
LEVEL
EQ
LINE2
ON/OFF
MIC
QUANTIZE
REV
FWD
STANDBY/ON
0
9
9
9
9
9
0
TEMPO
6
WIDE
10 16
SE
AR
CH
AUTO CUE
UTILITY
TIME
rekordbox
MIDI
USB
AUTO
BEAT LOOP
MASTER
MASTER
TEMPO
SYNC
TEMPO
SHIFT
CUE
PLAY/PAUSE
INFO
FX SELECT
TRANS
FLANGER
ROLL
ECHO
LEVEL/DEPTH
BEAT
BACK
QUANTIZE
REV
FWD
TEMPO
6
WIDE
10 16
1
2
3
4
1
2
3
4
BA
NK
JOG
DR
UM
SAMPLE
LA
UNCH
3
4
5
d
1
8
9
k
l
m
n
s
r
t
p
k
l
m
n
o
o
p
6
7
a
b
j
2
c
e
f
g
h i
3
4
5
d
1
8
9
6
7
a
b
j
2
c
e
f
g
h i
q
u
v
w
w
1. Player
No
XDJ-AERO buttons
Function
When SHIFT button is on
1
Rotary selector (turn)
Move cursor up/down
Move cursor up/down
Rotary selector (press)
When a track is selected: Load
When a folder is selected: Open folder
Browser Zoom
2
BACK button
When a track is selected: Move cursor to folder
When a folder is selected: Open/Close folder
—
3
PLAY/PAUSE button
Play/Pause
Stutter Play
4
CUE button
Cue Set/Play, Cue back
Jump To Track Start
5
AUTO BEAT LOOP control (turn)
Auto Loop Size Select Half & Double
Move Grid
AUTO BEAT LOOP control (press)
Auto Loop On/Off
Reloop
6
JOG DRUM button
Switch jog mode *
1
—
7
SAMPLE LAUNCH button
Switch FX/hot cue/sampler *
2
—
8
MASTER TEMPO button
keylock On/Off
keylock On/Off
9
TEMPO RANGE button
Tempo Range (6% 10% 16% 100%)
Switch panel *
3
a
SYNC button
Beat Sync
Master Deck Select
b
TEMPO adjustment control
Tempo Control
Tempo Control
c
Jog dial (turn outer section)
JOG DRUM Off (Vinyl)
Pitch Bend
—
JOG DRUM Off (CD)
Pitch Bend
—
JOG DRUM On
Pitch Bend
—
Jog dial (turn top)
JOG DRUM Off (Vinyl)
Scratch
Search
JOG DRUM Off (CD)
Pitch Bend
Search
JOG DRUM On
—
Search *
4
Jog dial (press top)
JOG DRUM Off (Vinyl)
Scratch On
—
JOG DRUM Off (CD)
—
—
JOG DRUM On
Cue Set/Play, Cue back
—
d
SHIFT
Shift
—
*1 The jog mode switches each time the JOG DRUM button is pressed.
When the JOG DRUM button is off (lit dimly), the XDJ-AERO operates in the vinyl mode (jog dial indicators lit blue) or CD mode (jog dial
indicators lit blue, flashing red).
When the JOG DRUM button is on (lit brightly), the jog dial functions in the same way as the CUE button (jog dial indicators lit red). The mode
switches between the vinyl and CD mode when the JOG DRUM button is pressed and held for 1 second then released.
*2 Each time the SAMPLE LAUNCH button is pressed, buttons 15 to 18 switch between the effect mode and the hot cue mode. When pressed
and held for over 1 second, the mode switches to the sampler mode. When the SAMPLE LAUNCH button is pressed in the sampler mode, the
mode switches to the hot cue mode. The SAMPLE LAUNCH button’s LED lights dimly when in the effect mode, brightly when in the hot cue
mode, and flashes when in the sampler mode.
*3 With the default 4-deck skin, the panel display on the deck switches in the following order:
“PLAYER” “LOOPS” “EFFECTS” “PLAYER” …
*4 The XDJ-AERO only operates when in the play mode.
