Additional information 14
53
En
Note
• When the auto power off is set to ON, “APD ON” will be
displayed on the main display.
• When the auto power off is set to OFF, “APD OFF” will be
displayed on the main display.
Setting quick start mode
Quick start mode significantly reduces the time required for
startup. It also allows the unit to power on automatically using
AirPlay and DLNA. Follow the steps below to turn on quick
start mode.
Power consumption increases when set to quick start mode
when compared to regular standby mode.
Setting quick start mode
1 Press  STANDBY/ON.
After the power turns on, it takes approximately 30 seconds
for the unit to be ready to use.
2 Hold the INPUT depressed for 3 seconds.
Quick start mode has been turned on.
“QUICK START ON” is shown on the main display.
Canceling quick start mode
1 Hold the INPUT depressed for 3 seconds
when the unit is in the quick start mode.
The quick start mode will be canceled.
“QUICK START OFF” is shown on the main display.
Restoring all the settings to the
defaults
Use the steps below to restore all the settings to their defaults.
Conduct the operation without any disc inserted (“NO DISC”).
1 Press  STANDBY/ON to turn the power on.
2 Press CD on the remote control or INPUT
repeatedly on the main unit to select CD input.
3 Press  STANDBY/ON and 
simultaneously.
Use the buttons on this unit’s top panel. “DEFAULT” is
displayed while the settings are being restored. Power is
turned off.
Specifications
• Amplifier section
RMS Power Output: . . . . . . . . . . . . . . . . . . . . . . . 20 W + 20 W
(1 kHz, 10 %, T.H.D., 8 )
• Tuner section
Frequency Range (FM) . . . . . . . . . . . . . .87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . . . . . . . . . . . . 75  unbalanced
• Network
WLAN standards . . . . . . . . . . . . . .IEEE 802.11b, IEEE 802.11g
Frequency band . . . . . . . . . . . . . . . . . . 2.412 GHz to 2.472 GHz
(2.4 GHz ISM Band, 13 Channels)
Channel 1 to Channel 13
Modulation . . . . . . . . . . 802.11b mode (DS-SS: IEEE 802.11b)
802.11g mode (OFDM: IEEE 802.11g)
• Miscellaneous
iPod/iPhone dock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 V, 1 A
USB terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 V, 2.1 A
Power source . . . . . . . . . . . . . .AC 100 V to 240 V, 50 Hz/60 Hz
Power consumption
Power on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 W
Power stand-by*. . . . . . . . . . . . . . . . . . . . . . . . .0.5 W or less
Power stand-by (Quick start mode)* . . . . . . . . . 3 W or less
*When not being charged
Dimensions. . . . . . . 520 mm (W) x 218 mm (H) x 137 mm (D)
Weight (without package) . . . . . . . . . . . . . . . . . . . . . . . . .3.9 kg
• Speaker
Type
Passive radiator
Fullrange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.6 cm cone
Passive radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.7 cm cone
Playback frequency range. . . . . . . . . . . . . . . . 60 Hz to 20 kHz
• Accessories
Remote control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
AC adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
AAA batteries (R03) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
iPad stand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Warranty card
Quick start guide
Operating instructions (CD-ROM)
Note
• CD-ROM: Cannot be played on this unit.
• Specifications and the design are subject to possible
modifications without notice, due to improvements.
• iOS is a trademark on which Cisco holds the trademark
right in the US and certain other countries.
