12
Amplifier Section
Continuous power output
(both channels driven at 20 Hz to 20 kHz)**
T.H.D. 0.06 %, 8 Ω ............................................ 45 W + 45 W*
T.H.D. 0.09 %, 4
Ω
............................................ 65 W + 65 W*
DIN Continuous power output (both channels driven at 1 kHz)
T.H.D. 1.0 %, 8 Ω ................................................ 60 W + 60 W
T.H.D. 1.0 %, 4 Ω ................................................ 90 W + 90 W
Total harmonic distortion**
20 Hz to 20 kHz, 20 W, 8
Ω
......................................... 0.05 %*
÷ Power output specification is for when power supply is 230V.
Input sensitivity/ impedance
PHONO (MM) ................................................... 2.8 mV/ 50 k
Ω
CD, TUNER, LINE/SB, TAPE 1/CD-R/MD,
TAPE 2 MONITOR ........................................... 200 mV/ 50 k
Ω
PHONO (MM) overload level
1 kHz, T.H.D. 0.1 % ...................................................... 150 mV
Output level/ impedance
TAPE 1/CD-R/MD, TAPE 2 MONITOR output
............................................................................ 200 mV/ 1 k
Ω
Frequency response
PHONO (MM) ................................. 20 Hz to 20 kHz
±
0.5 dB
CD, TUNER, LINE/SB, TAPE 1/CD-R/MD,
TAPE 2 MONITOR .............................. 5 Hz to 100 kHz dB*
Tone control
BASS ..............................................................
±
8 dB (100 Hz)
TREBLE ...........................................................
±
8 dB (10 kHz)
Loudness contour (volume control set at – 30 dB position)
.............................................. + 5 dB (100 Hz)/ + 3 dB (10 kHz)
Printed in Japan
Signal-to-Noise ratio (IHF short circuit, A network)
PHONO (MM, 5 mV input) ........................................... 86 dB*
CD, TUNER, LINE/SB, TAPE 1/CD-R/MD,
TAPE 2 MONITOR ...................................................... 106 dB*
Signal-to-Noise ratio (DIN, continuous power/ 50 mW)
PHONO (MM) ................................................... 71 dB/ 67 dB*
CD, TUNER, LINE/SB, TAPE 1/CD-R/MD,
TAPE 2 MONITOR ............................................ 95 dB/ 71 dB*
Power Supply/ Miscellaneous
Power requirements ............................ AC 220 - 230 V, 50/ 60 Hz
Power consumption ............................................................ 160 W
Power consumption in standby mode .................................. 1 W
AC outlet
Switched (x1) ..................................................................... 100W
Dimensions (including knobs and other protruding parts)
............................................. 420 (W) X 335 (D) X 128 (H) mm
Weight (without package)
......................................................................................... 6.9 kg
Accessories
Remote control unit ..................................................................... 1
Batteries (AA/R6P) ........................................................................ 2
Operating instructions ................................................................. 1
Power cord(Rated current 2.5 A) ................................................. 1
Warranty card ............................................................................... 1
NOTE:
Specifications and design subject to possible modification with-
out notice, due to improvements.
* Measured with the DIRECT/SB MODE button set to on.
(at DIRECT ON mode, SB OFF mode)
** Measured by Audio Spectrum Analyzer.
+0
- 3
MAINTENANCE OF EXTERNAL SURFACES
• Use a polishing cloth or dry cloth to wipe off dust and dirt.
• When the surfaces are very dirty, wipe with a soft cloth
dipped in some neutral cleanser diluted five or six times with
water, and wrung out well, and then wipe again with a dry
cloth. Do not use furniture wax or cleaners.
• Never use thinners, benzine, insecticide sprays and other
chemicals on or near this unit, since these will corrode the
surfaces.
Published by Pioneer Corporation.
Copyright © 2000 Pioneer Corporation.
All rights reserved.
