Page 5

5
En
4-
φ13.5X22
80
98
277
(493)
146
40
1157
67
123
(530)
496
300
980
800
1218
200
300
φ70
φ240.5
216
61
5
R
672
R
45°
45°
φ60.5
329
100
7 Dimensions
Weight ............... 14.5 kg (32.0 lbs) (Ceiling mount unit only)
53.4 kg (117.7 lbs) (Ceiling mount unit + Plasma Display
This diagram indicates the dimensions of the PDP-503CMX or PDP-503MXE plasma display after installation.
(Unit: mm)
Published by Pioneer Corporation.
Copyright © 2001 Pioneer Corporation.
All rights reserved.
This circle shows the path that the outer-
most part of the plasma display follows
when it is rotated about a vertical axis af-
ter having been tilted sideways by 25°.
This circle shows the path that the outer-
most part of the plasma display follows
when it is rotated about a vertical axis af-
ter having been tilted sideways by 25°.
Components and Quantities
PDP bracket .............................................. 1
Bolt M8 ..................................................... 6
Special screw (M5) .................................... 4
Stencil
(printed on the wrapping material that is inside) ...
1
Instruction manual ..................................... 1
Installer's contact information
(Japan only) ....
1
