Hide-away TV Tuner
(e.g. GEX-P7000TVP)
(sold separately)
Multi-Channel AV
Master Unit (e.g. AVM-P9000R)
(sold separately)
Green
RCA cable
(sold separately)
Blue
Yellow
20 pin cable
(supplied with the TV tuner)
IP-BUS cable
(supplied with the TV tuner)
Blue
Black
Red
Green
FM MODULATOR
IP-BUS MAIN UNIT
IP-BUS AV MASTER
Blue
Red
RGB cable
(supplied with the Multi-
Channel AV Master Unit)
Red
Yellow
White (Left)
Red (Right)
AV cable
(supplied with the
Multi-Channel AV
Master Unit)
Gray
3
Connecting the Units
When Connecting the Multi-Channel AV Master Unit
