43
Audio Adjustment
Equalizer Curve Fine Adjustment
You can adjust the center frequency and the Q factor (curve characteristics) of each cur-
rently selected curve band (EQ Low/EQ Mid/EQ High).
1. Press the AUDIO button for 2 seconds to select Equalizer Curve Fine
Adjustment.
Note:
• If you make adjustments when a curve other than “CUSTOM 2” is selected, “CUSTOM 1” curve is
updated.
4. Select the desired Q factor with
the
5/∞ buttons.
2N
+= 1N += 1W += 2W
3. Select the desired frequency with
the
2/3 buttons.
LOW: 40
Ф 80 Ф 100 Ф 160 (Hz)
MID: 200
Ф 500 Ф 1k Ô 2k (Hz)
HIGH: 3.15k
Ô 8k Ô 10k Ô 12.5k (Hz)
2. Press the AUDIO button to select
the desired band for adjustment.
Level (dB)
Center frequency Frequency (Hz)
Q=2N Q=2W
