Pannello posteriore
a Cavo di alimentazione CA
Viene inserito nella fonte di alimentazione
elettrica.
b Connettori altoparlanti
c Connettore antenna FM
d Connettore SCART
e VIDEO OUT
f AUX (L/R) INPUT
g HDMI OUT (tipo A, Versione 1.3) Collega la
TV agli ingressi HDMI.
h COMPONENT VIDEO (Y Pb Pr)
OUTPUT (PROGRESSIVE SCAN)
a
b
c
d
e f
h
g
