Note: (This note applies only to engines used in the U.S.A.) Maintenance, replacement or repair of the emission control devices and systems may be performed
by any nonroad engine repair establishment or individual. However, to obtain no charge repairs under the terms and provisions of the Briggs & Stratton
warranty statement, any service or emission control part repair or replacement must be performed by a factory authorized dealer.
How To Use Manual Figures
¡
--
¨
refer to figures inside covers.
-- refer to engine components in figure
¡
.
➊
--
➒
refer to part/action in figures.
19 1
Record your engine Model, Type and Code numbers
here for future use.
Record your date of purchase here for future use.
Technical Information
POWER RATINGS: The power ratings for an individual
engine model are initially developed by starting with
SAE (Society of Automotive Engineers) code J1940
(Small Engine Power & Torque Rating Procedure) (Re-
vision 2002-05). Given both the wide array of products
on which our engines are placed, and the variety of en-
vironmental issues applicable to operating the equip-
ment, it may be that the engine you have purchased will
not develop the rated horsepower when used in a piece
of power equipment (actual “on-site” power). This dif-
ference is due to a variety of factors including, but not
limited to, the following: differences in altitude, temper-
ature, barometric pressure, humidity, fuel, engine lu-
brication, maximum governed engine speed, individual
engine to engine variability, design of the particular
piece of power equipment, the manner in which the en-
gine is operated, engine run-in to reduce friction and
clean out of combustion chambers, adjustments to the
valves and carburetor, and other factors. The power
ratings may also be adjusted based on comparisons to
other similar engines utilized in similar applications,
and will therefore not necessarily match the values de-
rived using the foregoing codes.
Engine Components
(see fig. ¡ )
1 Carburetor
2 Air cleaner
3 Rotating screen
4 Engine Model
Type Code
xxxxxx xxxx xx xxxxxxxx
5 Spark plug wire
6 Muffler/Spark arrester, if equipped
7 Oil drain plug
8 Oil fill/Dipstick
9 12V electric starter, if equipped
10 Fuel filter
11 Blower housing
Hazard Symbols and Meanings
Explosion Toxic Fumes
Moving Parts Shock
Hot Surface
Kickback
Fire
International Symbols and Meanings
On Off
Fuel Shutoff
Read Owner’s
Manual
Stop
Fuel
Choke Safety Alert
Oil
Safety Precautions
* Briggs & Stratton does not necessarily know what
equipment this engine will power. For that reason,
you should carefully read and understand the
operating instructions for the equipment on which
your engine is placed.
BEFORE OPERATING ENGINE
• Read entire Operating & Maintenance Instructions
AND the instructions for the equipment this engine
powers.*
• Failure to follow instructions could result in serious
injury or death.
THE OPERATING & MAINTENANCE
INSTRUCTIONS CONTAIN SAFETY
INFORMATION TO
• Make you aware of hazards associated with engines
• Inform you of the risk of injury associated with those
hazards, and
• Tell you how to avoid or reduce the risk of injury.
The safety alert symbol is used to identify safety
information about hazards that can result in personal injury.
A signal word (DANGER, WARNING, or CAUTION) is used
with the alert symbol to indicate the likelihood and the potential
severity of injury. In addition, a hazard symbol may be used to
represent the type of hazard.
DANGER indicates a hazard which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
might result in minor or moderate injury.
CAUTION
,
when used without the alert symbol,
indicates a situation that could result in damage to
the engine.
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
WARNING
