EN 20
En
4. How to connect the underwater flash
Connecting the underwater optical fiber cable
To connect the UFL-2 underwater flash (optional) to the Case using an
underwater optical fiber cable (optional: PTCB-E02), follow the
procedures below.
Setting of the digital camera
Set the RC mode of the camera to ON so that the camera's built-in flash
is activated.
In case of UFL-2, turn the RC mode to OFF.
For details, refer to the instruction manual of UFL-2.
In case of UFL-1, plug the optical fiber cable in the same way.
Turn the RC mode of the camera to OFF.
How to connect the underwater
optical fiber cable
1 Remove the diffuser.
2 Put the underwater optical fiber
cable plug all the way into the
optical fiber cable insertion slot.
Tip:
When using the optional underwater flash, use the optional flash window
cover PFC-050 in order to reduce the color unevernness caused by the flash.
