Olympus Stylus 120 - Manual (Page 4)

6 7
Battery is OK. You can shoot.
Battery is low and will need to be replaced
within the next few photos.
Battery is dead and must be replaced with
a new one immediately.
lights (turns off
automatically).
blinks and other indicators
are displayed normally.
blinks and other indicators
go out.
2
3
Use one 3 V lithium battery (CR123A or DL123A).
1. While pressing the bottom of
the battery compartment
cover in direction
1 , turn it
in direction 2 to open.
USING THE STRAP
Attach the strap as shown.
Turn the diopter
adjustment dial until the
autofocus marks are
clear.
If you are nearsighted, turn the
dial up. If you are farsighted,
turn it down.
DIOPTER ADJUSTMENT
LOADING AND CHECKING THE BATTERY
Make sure the lens barrier is
closed before opening the
battery compartment cover.
2. Insert the battery correctly.
Close the battery compart-
ment cover.
A brand-new battery lasts for
about 15 rolls of film.
3. Slide the lens barrier in
direction 1 until it clicks.
Check the remaining battery
power on the LCD panel.
1
2754 Q20N_EN 02.11.18, 8:44 PM 6-7
