Olympus Stylus 80 - Manual (Page 12)

22 23
Flash modes: Auto Flash (automatic flash activation in low-light,
backlight and fluorescent light), Red-Eye
Reduction Flash (same as Auto otherwise), Flash-
Off (flash override with shutter speed extended to
2-sec. max.), Fill-In (forced activation), Night
Scene flash (with shutter speed extended to 4-sec.
max.) and Red-Eye Reduction Night Scene Flash
(with shutter speed extended to 4-sec. max.)
Exposure modes: Auto Exposure, Spot Metering and Infinity.
Other modes: Selftimer, Remote Control and Camera Shake
Indicator.
Battery check: Displayed on LCD panel.
Power source: One 3 V lithium battery (CR2).
Dimensions: 111.5 (W) x 59 (H) x 40 (D) mm (4.4 x 2.3 x 1.6
in) (excluding protrusions).
Weight: 180 g (6.4 oz) (without batterry).
Weatherproof feature:Equivalent to IEC Standard publication 529 IPX4
(under OLYMPUS test conditions).
࡯ Date Unit Specifications (Quartzdate model)
Types of data recording:
(1) None. (2) Year-month-day. (3) Month-day-
year. (4) Day-month-year. (5) Day-hour-minute.
External display of recorded data:
Continuous LCD panel display.
Automatic calendar function:
To year 2035.
࡯ Remote Control RC-300C Specifications (Optional)
Remote control system:
Infrared.
Power source: One CR2025 battery.
Battery life: Approx. 5 years.
Usage: Approx. 20,000 times.
Working distance: Approx. 5 m (16.4 ft).
Dimensions: 33 (W) x 56 (H) x 7 (D) mm (1.3 x 2.2 x 0.3 in)
Weight: 11 g (0.4 oz) (without battery).
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE OR
OBLIGATION ON THE PART OF THE MANUFACTURER. THE ACTUAL
PRODUCT MAY DIFFER FROM ONES SHOWN IN THIS MANUAL.
Type: Fully automatic 35 mm autofocus lens-shutter
camera with built-in 38 ~ 80 mm zoom lens.
Film format: 35 mm standard DX-coded film (24 x 36 mm).
Lens: Olympus lens, 38 ~ 80 mm, F5.3 ~ 10.4,
5 elements in 4 groups.
Shutter: Programmed electronic shutter.
Viewfinder: Real image zoom view viewfinder (with autofocus
marks, close-up correction marks, green lamp
[autofocus indicator], orange lamp [flash
indicator]).
Focusing: Passive-type multi-autofocus system (max.11
points). Focus lock possible. Focusing range – 0.6
m (2.0 ft) ~
∞ (infinity).
Exposure control: Programmed automatic exposure control, 2-zone
light metering. Auto exposure range – EV2.8
(F5.3, 4 sec) ~ EV16 (F11.4, 1/500 sec) at wide
angle, EV4.8 (F10.4, 4 sec) ~ EV17 (F19, 1/360
sec) at telephoto.
Exposure counter: Progressive type displayed on LCD panel.
Selftimer: Electronic selftimer with approx. 12-sec. delay.
Remote control: Infrared remote control unit with approx. 3-sec. delay.
Film speed range: Automatic setting with DX-coded film (ISO50, 100,
200, 400, 800, 1600 or 3200). Other intermediate
film speeds will be automatically set for next lower
speed. Non-DX-coded film is set at ISO100.
Film loading: Automatic loading. (Automatically advances to
first frame when camera back is closed.)
Film advance: Automatic film winding.
Film rewind: Automatic film rewind (automatic rewind activation
at end of film, automatic rewind stop). Rewind
possible at any point with mid-roll rewind button.
Flash: Built-in flash. Recycling time – Approx. 0.5 ~ 6
sec. (at normal temperature, with new battery).
Flash working range – 0.6 ~ 3.5 m (2.0 ~11.5 ft)
at wide angle and 0.6 ~ 1.8 m (2.0 ~ 5.9 ft) at
telephoto with ISO 100 color negative film; 0.6~
7.0 m (2.0 ~ 23.0 ft) at wide angle and 0.6 ~ 3.6
m (2.0 ~ 11.8 ft) at telephoto with ISO400 color
negative film.
SPECIFICATIONS
