B101075-1-0807
Attach the grease cup bracket assembly (10) to the
bottom of the grill casting and fasten with 10-24 x 3/4"
bolt, 9/32 ID x 5/8 OD washer, and #10-24 wing nut.
Figure 4.
Loosen the wing nut and move the slide up or down to
accept the grease cup. Be sure to trap the rim of the
cup as shown.
Use only the supplied grease cup or noncombustible
containers for the grease cup (aluminum or tin cans).
DO NOT use combustible containers such as Styrofoam
or paper cups.
Continue assembly as directed by the Owner’s Manual
packaged with the grill head.
Attach the control housing (6) using two #8 x 1/2" Phillips
Truss screws or two plastic panel fasteners as shown
in Figure 5.
BROILMASTER ®
is a registered trademark of
Empire Comfort Systems, Inc.
918 Freeburg Ave.
Belleville, Illinois 62220
Phone: 1-800-851-3153
FAX: 1-800-443-8648
V
ISIT OUR WEB SITE AT WWW
.broilmaster.com
P
ATIO
B
ASE
A
SSEMBLY
6
Figure 4
Figure 5
7
8
