Beltronics STi-R User Manual
Page 3
Table of Contents
Quick Reference Card
1-2
Quick Reference Guide
4-5
Controls and Features
6-9
• Power
6
• Volume Control
6
• Power-on Indication
6
• Voice Alerts
6
• AutoMute
6
• Mute
6
• Sensitivity Button
7
• Brightness
7
• Audible Alerts
8
• Signal Strength Meter
8
• Threat Display
9
• Tech Display
9
Programming
10-14
• How to use Programming
10
• Example of Programming
10
• Overview of Programming
11
• Details of Programming
12-14
Technical Details
15-21
• Specifications
15
• Interpreting Alerts
16-17
• How Radar Works
18
• How “POP” Works
18
• How Laser Works
19
• How TotalShield
™
Technology Works 20
• How Safety Radar Works
20-21
Service
22-28
• Troubleshooting
22-23
• Service
24
• Warranty
25
• Registration
27-28
3
2
Quick Reference Card
BELTRONICS STi-R
Quick Reference Card
Remove card along perforations
Re
mo
ve c
ard
alo
ng p
erfo
ratio
ns
Press the VOL/MUTE button
Press the SENS button
to go from one category
to change your setting
to the next
within a category
PILOT
Pilot HWY
* Full word: Highway, AutoScan, etc.
(Power-on indication)
Pilot H
Letter: H, A, C, or Cnx
Pilot V
Vehicle voltage
VOICE
Voice ON
* Voice alerts on
Voice OFF
Voice alerts off
POWER-ON SEQUENCE
PwrOn STD
* Standard power-on sequence
PwrOn FST
Fast power-on sequence
SIGNAL STRENGTH METER
Meter STD
* Standard signal strength meter
Meter THT
Threat Display
Meter TEC
Tech Display
AUTOMUTE
aMute ON
* AutoMute on
aMute OFF
AutoMute off
BRIGHTNESS
Brt Auto
* Automatic brightness
Brt Min
Minimum brightness
Brt Med
Medium brightness
Brt Max
Maximum brightness
Brt Dark
All dark
BANDS
Bands DFT
* Factory default settings
Bands MOD
Factory default settings modified
Turn bands “ON” or “OFF” by press-
ing and holding the “SENS” button
X
ON
or
OFF
(default is on)
K
ON
or
OFF
(default is on)
KaSW ON
or
OFF
(default is on)
LSR ON
or
OFF
(default is on)
SWS ON
or
OFF
(default is off)
POP ON
or
OFF
(default is off)
RDR ON
or
OFF
(default is on)
* Factory Default Settings
When KaSW is off,
each Ka segment can be turned on or off
Ka1
(33.392 - 33.704)
ON
or
OFF
Ka2
(33.704 - 33.896)
ON
or
OFF
Ka3
(33.886 - 34.198)
ON
or
OFF
Ka4
(34.184 - 34.592)
ON
or
OFF
Ka5
(34.592 - 34.808)
ON
or
OFF
Ka6
(34.806 - 35.166)
ON
or
OFF
Ka7
(34.143 - 35.383)
ON
or
OFF
Ka8
(35.378 - 35.618)
ON
or
OFF
Ka9
(35.595 - 35.835)
ON
or
OFF
Ka10
(35.830 - 35.998)
ON
or
OFF
