Please read both sides of these instructions before starting your installation.

For the easiest trouble-free installation, install the Interface first, and wire it to a

12-volt switched circuit.

Then before installing the other components, plug all of them into the Interface

and power up the unit to confirm proper operation.

Read This First

A professional installer must install your
new

. Installation of

this system requires experience and
expertise in automotive electronics. Car
Audio specialists and many car dealers
can install

for you.

Attempting to install this product
without expertise in automotive
electronics installation can cause
personal injury, or damage to your
vehicle.

If your vehicle is damaged during
installation, its safety systems may be
compromised, which could cause
personal injury or property damage.

Improper installation may void
the warranty.

BEL

To get the best performance possible, the
mounting location of the Radar Receiver is
critical. Although radar signals will pass
through some types of plastic, mounting
the Radar Receiver so that it has a clear
“view” of the road will ensure maximum
warning.

Since Laser signals will not pass through
any objects, including plastic, it is critical
that the Laser Receivers be mounted
perfectly level, and have an unobstructed
“view” of the road.

Important Installation Warnings

Performance Warning

IMPORTANT NOTES

Front Radar Receiver

• Miniature weather-proof Radar Receiver
• Universal mounting bracket with stainless steel hardware
• Built-in 6 foot shielded cable with waterproof connector
• 13 foot shielded cable with in-line grommet and waterproof

connector

• 12 nylon wire ties to secure cable

Front Laser “Blockers”

• Weather-proof sensor
• 13 foot shielded cable with in-line grommet
• Universal mounting bracket with stainless steel hardware

User Display

• User Display mounts easily to instrument pod, dashboard,

or console

• Velcro and adhesive pads provided for secure mounting

Interface

• Central module connects to switched 12-volt power and ground
• All components plug directly in using modular connections
• 3M connector taps into existing vehicle wiring

Rear Laser Receiver

• Weatherproof license plate mounted sensor
• 30-foot cable with modular connector

Documentation

• Comprehensive Owner’s Manual
• Installation Manual

Built-in Diagnostics

• Confirms all components are operational

™

is a trademark of SWS LC. Features, specifications and prices subject to change without notice.

M O D E L R X 7 5 P L U S

CUSTOM INST

ALLED

D A

RDETECT

ORA

L ASER

“BL OCKING” SY

STEM
