Note: With the help of a friend,

turn the cart to its upright
position.

Step 4

Attach back cart panel by using
four M6 X 50mm bolts.

Note: Leave bolts hand tight until

Step 9.

Step 5

Install door bracket using the four
M6 X 50mm bolts. Make sure door
stop is set toward front of cart.

Note: Leave bolts hand tight until

Step 9.

Step 6

Attach the grease cup bracket onto
the back cart panel by inserting the
three tabs into the slots on the back
cart panel.

Grease Cup Bracket
