• Adjust the plug and socket connections together correctly.
• Install correctly to give shock protection.
• Loose and incorrect plug and socket connections can make the terminal become too
hot.
• A qualified electrician must install the connections in the clamps correctly.
The appliance must have the electrical installation which lets you disconnect the appli-
ance from the mains at all poles with a contact opening width of minimum 3 mm.
You must have correct devices to isolate: line protecting cut-outs, fuses (screw type
fuses removed from the holder), earth leakage trips and contactors.
Assembly
min. 500 mm
min.
50 mm
min.
50 mm 600
mm
490 +1mm
750 +1mm
=
=
R 5
mm
min.
28 mm
20 Installation instructions
