PARTS NAMES AND FUNCTIONS
Front Panel LED Indications
LED
Status Description
POWER ON
Power
On
ON A valid connection
LINK/ACT
Blinks Receives packets
ON
Connects to a 100Mbps
Fast Ethernet connection
SPD
OFF
Connects to a 10Mbps
Ethernet connection
Ethernet Ports (1-8)
Ethernet Ports with MDI/MDIX auto crossover
capacity.
Power Port
Connect to the External power adapter.
- 3 -
