AG Neovo F-415 - Manual

P/C: F15J0 Version 13.0, 20070720
Panel Panel Type TFT LCD
Panel Size 15" (381mm)
Max. Resolution XGA 1024 x 768
Pixel Pitch 0.297mm
Brightness 250cd/m 2 (Typical)
Contrast Ratio 500:1 (Typical)
Surface Treatments Hard Coating (3H), Anti-glare
Treatment
Viewing Angle (H/V) 150 °/130° (Typical)
Display Color 16.7M
Response Time 4ms (GTG)
Frequency (H/V) H: 24kHz - 61kHz
V: 56Hz - 75Hz
Max. Pixel Clock 80MHz
Life Time 40,000hrs (Typical)
Inputs Analog 15-Pin D-Sub
Connector Power 3-Pin AC Inlet
Tilt Tilt -5 ° ~ +30°
Mounting VESA FPMPMI Yes (75mm)
Regulation
Approval Certifications &
Compliance UL/CUL, Energy Star, CB,
TUV/GS, FCC, TCO 99,CE,
BSMI, GOST, NORDIC, WEEE,
RoHS
VESA DDC 1/2B, DPMS
Power Power AC 100 - 240V, 50 - 60Hz
Consumption <40W (On)
<2W (Stand-by)
<1W (Off)
Dimensions Net (W x H x D) 350 x 335 x 180mm
(13.8" x 13.2" x 7.1")
Packing (W x H x D) 442 x 393 x 120mm
(17.4" x 15.4" x 4.7")
Weight Net Weight 3.7Kg (8.2 lbs)
Gross Weight 5.3Kg (11.7 lbs)
Packing 1 Pallet 100 Cartons
20’ Container 1,000 Sets
40’ Container 2,200 Sets
All specifications are subject to change without prior notice
f 15” LCD DISPLAY f SPECIFICATION
F-415
www.agneovo.com
Copyright © 2007 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
f FEATURES
Slim and sleek design
Swift 4ms response time
High 500 contrast ratio
Built-in power supply
Cable management organiser
Kensington  security socket
VESA standard wall mount
Easy-to-use OSD
Three available colors: black, ivory, silver
