AG Neovo H-W19 - Manual

P/C: HW1900 Version 4.2, 20080312
Panel Panel Type TFT LCD
Panel Size 19.0" (481mm)
Max. Resolution WXGA + 1440 x 900
Pixel Pitch 0.285mm
Brightness 380cd/m 2 (Typical)
Contrast Ratio 1000:1 (Typical)
Surface Treatments Hard Coating (3H), Anti-glare
Treatment
Viewing Angle (H/V) 170 °/160° (Typical)
Display Color 16.7M
Response Time 3ms (GTG)
Frequency (H/V) H: 24kHz – 80kHz
V: 55Hz – 75Hz
Max. Pixel Clock 140MHz
Life Time 50,000hrs (Minimum)
Input Analog 15-Pin D-Sub
Audio Audio In 3.5mm Audio Line-in
Speaker 1W x 2
Connector Power 3-Pin AC Plug
Tilt Tilt -5 ° ~ +25°
Mounting VESA FPMPMI Yes (100mm)
Regulation
Approval Certifications &
Compliance UL/CUL, FCC, NOM, CB, CE,
TUV/GS, GOST-R/HYGIENIC,
Nordic, BSMI, Energy Star,
TCO’03, WEEE, RoHS
VESA DDC-2B, DDC-CI
Power Power AC 100 – 240V, 50 – 60Hz
Consumption <42W (On)
<2W (Stand-by)
<1W (Off)
Dimensions Net (W x H x D) 439 x 363 x 211 mm
(17.3” x 14.3” x 8.3”)
Packing (W x H x D) 509 x 442 x 188 mm
(20.0” x 16.6” x 7.4”)
Weight Net Weight 3.9 kg (8.6 lbs)
Gross Weight 5.3 kg (11.7 lbs)
Packing 1 Pallet 52 Sets
20’ Container 520 Sets
40’ Container 1144 Sets
All specifications are subject to change without prior notice
f SPECIFICATION f 19” WIDESCREEN LCD DISPLAY
H-W19
f FEATURES
19” widescreen format
WXGA + 1440 x 900 resolution
Slim and sleek design
Fast 3ms response time
High 380 brightness
Crisp 1000 contrast ratio
Built-in speakers
Easy-to-use friendly OSD
Auto-adjustment for optimal viewing
Kensington  security socket
VESA standard wall mount
Windows Vista Basic approved
TCO’03 certified
www.agneovo.com
Copyright © 2007 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
