28
° °
Product description: Multicompressor MV 10
Item number:
97181
Dimensions: approx. 24.5 x 13.3 x 21
cm (l x w x h cm)
Weight: approx. 1.55 kg
Fuse: 15 A (Ampere)
Operating
temperature:
0 C - 50 C (Celsius)
Compressor:
Compressor output: max. 10 bar / 145 PSI
(bar / PSI = pressure unit)
Pressure indicator /
Manometer gauge: Analogue pressure
readout, not calibrated,
with backlight
Manometer
tolerances:
+/- 0.34 bar (5 PSI) at
0 – 6.9 bar (0 -100 PSI)
+/- 0.48 bar (7 PSI) at
6.9 - 10 bar (100 -150 PSI)
Noise level: 95 dB (dB = volume)
Interval operation: max. 10 minutes operation,
min. 10 minutes cool down
Generator set: 1 cylinder, 1 membrane
Oil-free
Air hose length: approx. 65 cm
Lighting:
Light type:
4 LED lights
LED lights: LED lights are not
replaceable
Laser class: LED lights correspond to
Protection Class I
Units with protective
insulation with Protection
Class II
The unit complies with
EC Directives
▪
Machinery Directive
(2006/42/EC)
▪ Directive on
electromagnetic
compatibility
(2004/108/EC)
6.0 TECHNICAL
DATA
5.1.4 Do not store the unit in extreme temperature
fluctuations! This will result in condensation, which
can damage the electronics!
5.1.3 Only keep / store the unit in dry environ-
ments! Moisture can damage the unit's electron-
ics!
5.1.2 Clean the equipment with a dry cloth. Do
not use liquids or harsh cleaners as these may
cause discolouration and damage the unit's sur-
face, and possibly damage the unit! Do not allow
liquids to enter the equipment! Do not immerse the
unit in liquids! Only operate the unit when dry.
5.1.1 Warning! Power off the unit using the
operating switch and disconnect the 12 V auto-
motive plug from the vehicle's 12 V receptacle or
the separate power station with built-in 12 V
storage battery.
5.1 Cleaning, maintenance and storage
5.0 MAINTENANCE
AND CARE
