WARNING!
Make sure that the cut off plug is disposed of safely. A cut off plug put into a 13 amp sock-
et is a safety hazard. There is a risk of electrical shock.
The replacement of the electrical cable must be done by a qualified electrician or compe-
tent person, according to the current regulations.
Replacement of the connection cable
To replace the connection cable use only H05V2V2-F T90 or equivalent type. Make sure that
the cable section is applicable to the voltage and the working temperature. The yellow/
green earth wire must be approximately 2 cm longer than the brown (or black) phase wire.
Building In
min. 45 mm
min. 650 mm
830 mm
min. 450 mm
40 mm
480 mm
A
A - supplied seal
A
B
A - supplied seal
B - supplied brackets
Possibilities for insertion
Kitchen unit with door
The panel installed below the hob must be easy to remove and let an easy access in case a
technical assistance intervention is necessary.
Installation 11
