technIcal ManUal
1 . Prism cover
2 . Prism surface
3 . calibration screw
4 . Ocular
5 . adjustment ring
6 . cleaning clotch
7 . calibration tools
8 . Distilled Water
9 . storage Box
10 . Pipette
11 . refractometer
a: Meas . scale for determining battery acid density
B: anti-freeze scale
c: Measuring scale for windscreen washer fluid
C
B
A
6
7
8
9
11
10
1
2
3
4
5
