11
English
GB
BS 12G BS 14G BSB 12G BSB 14G
Drilling capacity in steel ........................................................................10 mm................10 mm...................10 mm ......................10 mm
Drilling capacity in steel (with chuck 1,5 - 13 mm) ................................. - ......................13 mm..................... - .............................13 mm
Drilling capacity in wood .......................................................................30 mm................32 mm...................30 mm ......................32 mm
Drilling capacity in wood (with chuck 1,5 - 13 mm) ................................ - ......................32 mm..................... - .............................32 mm
Drilling capacity in brick and tile ............................................................. - ........................ - ...........................6 mm ........................8 mm
Wood screws (without pre-drilling) .....................................................4,2 mm...............4,2 mm..................4,2 mm .....................4,2 mm
No-load speed, 1st gear .................................................................. 0-350 min -1 ........ 0-400 min -1 ........... 0-350 min -1 ...............0-400 min -1
No-load speed, 2nd gear ............................................................... 0-1350 min -1 ...... 0-1400 min -1 ......... 0-1350 min -1 .............0-1400 min -1
No-load speed, 2nd gear (Li-Ion) ............................................................ - .............. 0-1500 min -1 ................... - ......................0-1500 min -1
Rate of percussion under load max. ........................................................ - ........................ - ..................20 250 min -1 ............. 21 000 min -1
Rate of percussion under load max. (Li-Ion) ........................................... - ........................ - ........................... - ...................... 22 500 min -1
Torque * ................................................................................................30 Nm ................32 Nm ...................30 Nm .......................32 Nm
Torque * (Li-Ion) ......................................................................................- ......................36 Nm ..................... - .............................36 Nm
Battery voltage .....................................................................................12 V .................14,4 V .......................12 V........................14,4 V
Drill chuck range ............................................................................ 1,5-10 mm............ 1-10 mm............ 1,5-10 mm ...................1-10 mm
Drill chuck range .....................................................................................- ............... 1,5-13 mm..................... - .......................1,5-13 mm
Weight according EPTA-Procedure 01/2003 (1,4 Ah) .........................1,65 kg ...............1,95 kg ....................1,8 kg ........................2,1 kg
Weight according EPTA-Procedure 01/2003 (1,5 Ah Li-Ion) .................... - ...................1,52 kg ....................... - ..........................1,65 kg
Noise/Vibration Information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K=3dB(A)) .........................................................90 dB(A) ............90 dB(A) ..............90 dB(A) ................. 90 dB(A)
Sound power level (K=3dB(A)) ..........................................................101 dB(A) ..........101 dB(A) ............101 dB(A) ............... 101 dB(A)
Wear ear protectors!
Total vibration values (vector sum in the three axes) determined according to EN 60745.
Vibration emission value a
h
Impact drilling into concrete ...............................................................- ........................- ....................15,6 m/s2............... 13,7 m/s2
Uncertainty K ......................................................................................- ........................- ......................1,5 m/s2................. 1,5 m/s2
Drilling into metal .......................................................................< 2,5 m/s2 ....... < 2,5 m/s2 ..........< 2,5 m/s2..............< 2,5 m/s2
Uncertainty K ..................................................................................1,5 m/s2 ............1,5 m/s2 ..............1,5 m/s2................. 1,5 m/s2
Screwing .....................................................................................< 2,5 m/s2 ........< 2,5 m/s2 ..........< 2,5 m/s2..............< 2,5 m/s2
Uncertainty K ..................................................................................1,5 m/s2 ............1,5 m/s2 ..............1,5 m/s2................. 1,5 m/s2
* Measured according to AEG norm N 877318
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and
may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications, with
different accessories or poorly maintained, the vibration emission may differ. This may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is running
but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
TECHNICAL DATA Cordless Drill Driver, Cordless percussion drill/driver
