16 17
HBS 1000 E
..................... 4133 47 01...
..................... 4131 90 01...
...000001-999999
.......................1010 W
..................240-450 min -1
...........................75 mm
.........................533 mm
................... 75x145 mm
..........................5,1 kg
...........................88 dB (A)
...........................99 dB (A)
.......................< 2,5 m/s 2
..........................1,5 m/s 2
ENGLISH ENGLISH
TECHNICAL DATA Belt Sander
Production code.......................................................................
..............................................................................................
Rated input ..............................................................................
Belt speed no load ...................................................................
Sanding width ..........................................................................
Belt length................................................................................
Sanding surface.......................................................................
Weight according EPTA-Procedure 01/2003 ...........................
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) .......................................
Sound power level (K = 3 dB(A)) ............................................
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
Vibration emission value a
h
...................................................
Uncertainty K= ......................................................................
WARNING! Read all safety warnings and all
instructions, including those given in the accompanying
brochure. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause hearing
loss.
Use auxiliary handles supplied with the tool. Loss of
control can cause personal injury.
Hold power tool by insulated gripping surfaces,
because the belt may contact its own cord. Cutting a
"live" wire may make exposed metal parts of the power tool
"live" and shock the operator.
Appliances used at many different locations including open
air should be connected via a residual current device of
30 mA or less.
Always wear goggles when using the machine. It is
recommended to wear gloves, sturdy non slipping shoes
and apron.
Sawdust and splinters must not be removed while the
machine is running.
Always disconnect the plug from the socket before carrying
out any work on the machine.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.
Always lead the cable away behind you.
The dust produced when using this tool may be harmful to
health (e.g. when working oak or beech wood, stones, paint,
which could contain lead or other harmful chemicals). Do
not inhale the dust. Use a dust absorption system and wear
a suitable dust protection mask. Remove deposited dust
thoroughly, e.g. with a vacuum cleaner.
When grinding metal, flying sparks are produced. Take care
that no persons are endangered. Because of the danger of
fire, no combustible materials should be located in the
vicinity (spark flight zone). Do not use dust extraction.
SPECIFIED CONDITIONS OF USE
The belt sander can be used for sanding wood, plastics and
metal.
Do not use this product in any other way as stated for
normal use.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product
described under “Technical Data” fulfills all the relevant
regulations and the directives 2011/65/EU (RoHs),
2006/42/EC, 2004/108/EC and the following harmonized
standards have been used:
EN 60745-1:2009 + A11:2010
EN 60745-2-4:2009 + A11:2011
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
EN 61000-3-2:2006 + A1:2009 + A2:2009
EN 61000-3-3:2008
Winnenden, 2013-02-18
Alexander Krug
Managing Director
Authorized to compile the technical file.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
MAINS CONNECTION
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all
times.
Use only AEG accessories and spare parts. Should
components need to be exchanged which have not been
described, please contact one of our AEG service agents
(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the machine type printed as well as the six-digit
No. on the label and order the drawing at your local service
agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, 71364 Winnenden, Germany.
SYMBOLS
Please read the instructions carefully before
starting the machine.
Always disconnect the plug from the socket
before carrying out any work on the
machine.
Do not dispose of electric tools together
with household waste material!
In observance of European Directive
2002/96/EC on waste electrical and
electronic equipment and its
implementation in accordance with national
law, electric tools that have reached the end
of their life must be collected separately
and returned to an environmentally
compatible recycling facility.
Class II construction, tool in which
protection against electric shock does not
rely on basic insulation only, but in which
additional safety precautions, such as
double insulation or reinforced insulation,
are provided.
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
