1) Menu Button
2) Wide Button
3) Stop Button
4) Pause Button
5) Up Button
6) Play/OK Button
7) Right / Fast Forward Button
8) Down Button
9) Left / Fast Reverse Button
10) DC Input Jack
11) AV Jack
12) AV in/out SW
F. Controls, Indicators and Connectors
1. Unit View (Refer to Figure 3)
13) SD/MMC/MS Card Slot
14) USB Slot
15) Power ON/OFF Switch
16) Power ON LED Indicator
17) Remote Control Sensor
18) Open Switch
19)Brightness Up/Down Control
20) Volume Up/Down Control
21)Headphone Jack 2
22)Headphone Jack 1*
23)Charge Indicated LED
Figure 3
* Using headphone jack 1 will disable the internal speakers
16 17 18
1
2
3
4
5
6
7
8
9
9
10 11 12 13 14 15
20 19 21 22 23
