Labels supplied with the accessories bag
Stick the adhesive labels as indicated below:
MOD.
PROD.NO.
SER.NO
DATA
MOD.
PROD.NO.
SER.NO
DATA
MODEL
MODEL
MOD.
PROD.NO.
SER.NO.
03 IT
MADE IN ITALY
TYPE
230V-50Hz
IP20
0049
1
2
3
1
Stick it on Guarantee Card and send this part
2
Stick it on Guarantee Card and keep this part
3
Stick it on instruction booklet
These data are necessary to help you quickly and correctly. These data are available on
the supplied rating plate.
• Model description .................
• Product number (PNC) .................
• Serial Number (S.N.) .................
Use the original spare parts only. They are available at Service Force Centre and approved
spare parts shops.
TECHNICAL DATA
Hob dimensions
Width:
594 mm
Length:
510 mm
Hob recess dimensions
Width:
560 mm
Length:
480 mm
Heat input
Rapid burner:
3.0 kW
Semi-rapid burner:
2.0 kW
Auxiliary burner:
1.0 kW
Technical data
17
