2 Product Overview
This machine is not simply a conventional copier but a digital device capable of
copying, faxing, printing and scanning, depending on the configuration.
The appearance of the screen on your machine may differ slightly depending on the
model and configuration. However, feature descriptions and functionality described
here remain the same.
For information about available options not described here, visit the Xerox web site or
contact your Xerox Sales Representative.
Identifying the Machine Components
The following diagram shows the standard and optional components of the machine.
Configuration may vary depending on the model.
NOTE: Depending on the configuration, the Document Glass Cover is attached
instead of the Document Feeder. A maximum of three optional paper trays can be
attached.
B
A
C
D
Document Feeder
Document Glass
(under the Document Feeder)
Control Panel
Screen
Center Output Tray
Tray 5 (Bypass Tray)
Duplex Kit (Optional)
Front Cover
On / Off Switch
Tray 1
Tray 2 (Optional)
Tray 3 (Optional)
Tray 4 (Optional)
Connector (LINE)
Connector (TEL)
