Alcatel-Lucent 1353 Litespan Management System (LMS) 5
The Alcatel-Lucent 1353 LMS functions as a network element manager, an
end-to-end network manager of user services, as well as a subscriber manager.
It incorporates several management applications described in Table 1 and
illustrated in Figure 3. With, moreover, the Alcatel-Lucent 1353 LMS, all of
your applications can run on a single server, providing a cost advantage for
small networks.
Alcatel-Lucent 1353 LMS applications
Table 1. Alcatel-Lucent 1353 LMS management applications
APPLICATION FUNCTION
Alcatel-Lucent 1353 Distributed Network (DN) Element manager for voice and leased line data services delivered on the Alcatel-Lucent 1540
Litespan platform
Alcatel-Lucent 5523 ADSL Work Station (AMS) Element manager for xDSL broadband services delivered on the Alcatel-Lucent 1540 Litespan platform
Alcatel-Lucent 1353 NM (Network Management) Element manager for the optional integrated add-drop multiplexer (for synchronous digital hierarchy
(SDH) services) in the Alcatel-Lucent 1540 Litespan
Alcatel-Lucent 1353 PSM Element manager for the optional integrated Next Generation ADM (LINA), for SDH and Ethernet over
SDH services in the Alcatel-Lucent 1540 Litespan
Alcatel-Lucent 1353 GW (Gateway) Gateway application running on top of the element managers to interface with third-party operational
support systems (OSSs)
Alcatel-Lucent 1355 DN Subscriber manager for voice services delivered on the Alcatel-Lucent 1540 Litespan platform
Alcatel-Lucent 1355 GW Gateway application running on top of the Alcatel-Lucent 1355 DN to interface with third-party OSSs
Figure 3. Alcatel-Lucent 1353 LMS management applications
Element
management
Network
management
Web services
XML/SOAP
1540
Litespan
node
SNMP
SNMP
Alarms/PM
TFTP FT Q3 FT Q3
Broadband
services
NB – voice
leased lines
Synth
SDH
LINA
SDH EoS
5523
AMS
1353
DN
1355 DN
1353
NM
OSS
1353 LMS platform
1353 GW
1353 PSM
Linux, Solaris,
HP-UX
1355 GW
