Electric Convection Oven - Manual Control • Pg. 26.
S E R V I C E PA R T S L I S T
Description
ASC-2E
ASC-4E
Qty.
Cosmetic/Exterior Components
Panel, Top and Side
1005455
1006623
1
Gasket, LH/RH
1005311
1006605
2
Gasket, Top/Bottom
1005316
1006606
2
Panel, Service, louvered
1006602
1006672
1
Cover, Bottom
1005458
1006678
1
Cover, Top
1005459
1006679
1
Interior
Rack, Side
SR-26893
SR-26396
2
Shelf
SH-26894
SH-26795
5 / 6
Lamp, *CT, snap-in, oven light
—
LP-34161
2
Gasket, oven lamp
—
GS-26630
2
Glass, *CT, oven lamp
—
GL-26608
2
Cover for oven light
—
CV-26607
2
Receptacle, Lamp
—
RP-3986
1
Bulb, logo 15W
—
LP-3686
1
Bulb, 230/240V, 25W
—
LP-34206
2
Oven Elements
Element, Outer, 208V
EL-34211
—
1
Element, Inner, 208V
EL-34212
—
1
Element, Rear, 208V
—
EL-34126
1
Element, Center, 208V
—
EL-34127
1
Element, Front, 208V
—
EL-34128
1
Element, Inner, 240V
EL-34209
—
1
Element, Outer, 240V
EL-34210
—
1
Element, Rear, 240V
—
EL-34129
1
Element, Center, 240V
—
EL-34146
1
Element, Front, 240V
—
EL-34125
1
Motor/Blower Wheel
Motor, 208/240V
MO-34208
MO-34215
1
Wheel, Blower
WH-26895
WH-26405
1
Door Assembly
Assembly, Complete
5004352
—
1
Assembly, Complete, RH
—
5005407
1
Assembly, Complete, LH
—
5005409
1
Switches/Thermostats/Timers
Block, Terminal
BK-3597
BK-3597
1
Block, Modular
BK-25567
BK-25567
1
Buzzer
BZ-34113
BZ-34113
1
Contactors, *CT, 240V, 50A
CN-3731
CN-3731
1 / 2
Fan, Box, 70CFM, 230V, 50-60HZ
FA-3568
FA-3568
1
Fuse Holder, Dual, 15A, Class G
FU-3772
FU-3772
1
Fuses, *CT, 15A, Class G
FU-3775
FU-3775
2
Guard, Fan
GD-2396
GD-2396
1
Knob, Control, Indicating Timer
KN-34103
KN-34103
1
Knob, Thermostat
KN-34297
KN-34297
Light Indicator
LI-3025
LI-3025
1
Panel Overlay
PE-26978
PE-26729
1
Switch, Rocker, Fan, High/Low
SW-34101
SW-34101
1
Switch, On/Off/Cool-down
SW-34112
SW-34112
1
Switch, High Limit
SW-34150
SW-34150
1
Switch, Door, Roller
SW-34164
SW-34164
1
Switch, Motor Protect
SW-33500
—
1
Switch, Motor Protect
SW-33378
—
1
Timer, 250V, 1 hr
TR-34174
TR-34174
1
Thermostat, 140-500 °F
TT-34092
TT-34092
1
D A N G E R
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
