DESIGNER SOLUTIONS
400-0503-001 5
MECHANICAL UT250-101
Minimum Table Thickness 0.5 in (13 mm)
Maximum Table Thickness None
Length 9.9 in (251 mm)
Width 8.1 in (206 mm)
Height (body) 1.3 in (33 mm)
Height (with cable support) 6.1 in (154 mm)
Material Aluminum
Finish Silver
Net Weight 2.8 lb (1.27 kg)
Shipping Weight 3.3 lb (1.50 kg)
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
Table 2. UT250-101 Mechanical
ELECTRICAL UT250-101
Video Input Signal
Video Signal 1.2 Vp-p max
Video Impedance 75 ohms
SYNC Signal TTL (+/-)
SYNC Impedance 10 kohms
Audio Input Signal
Impedance 10 kohms
Level 1.0 Vp-p max
Output Select (I/O)
In = Momentary Switch to GND
Out = LED Internal Driver
Video Output Signal
Video Gain 0dB +/- 0.5 dB
Video Impedance 75 ohms
SYNC Signal TTL (+/-)
SYNC Impedance 22 ohms
Audio Output Signal
Impedance 50 ohms
Audio Gain 0dB +/- 0.5 dB
Twisted Pair Output
CAT-5/6 Twisted Pair (UTP)
Video/Sync/Audio
Signals
ALTINEX Standard
Power Consumption
External Adapter: 12 VDC 1.66 A (20 W)
Table 3. UT250-101 Electrical
