450599 - 2 www.amdry.com 13
Illus. No. Part No. Qty. Description
1 183129 2 #10-32 x 1/2” TORX ® Head Machine Screw
2 170168 1 Brush
3 818801 1 Lint Drawer
819345* 1 Lint Drawer Assembly Complete
(includes illus. nos. 1 through 7)
4 819344* 1 Cold Rolled Steel Lint Drawer Handle
5 819287 2 Lint Drawer Handle Fastening Plate Assembly
6 185226 1 Black Lint Screen Handle Molded
7 150334 2 #8-16 x 9/32” Phillips Pan Head Screw
* Specify color when ordering.
Lint Drawer Assembly
For Models Mfd. as of July 29, 2005
