XVC-1001-DC Guide to installation and operation
35
Inputs
Formats:
HD (SMPTE 292M) (1.485, 1.485/1001 Gbps)
720p50, 720p59.94, 1080i50, 1080i59.94
Format autodetected
Connectors: One (1) BNC
Return Loss: >14 dB up to 1.5 Gbps
Impedance: 75 Ω unbalanced
Video Outputs
Formats:
SD (SMPTE 259M-C) (270 Mbps)
480i59.94, 576i50
Connectors: Four (4) BNC
Return Loss: >17 dB up to 270 Mbps
Jitter: < 0.2 UI
Impedance: 75 Ω unbalanced
Reference
Connector: One (1) BNC, SMPTE 170
bi-level, tri-level
Control:
Inputs:
One (1) RJ-45 on frame
Software: Dashboard
Emedded Audio: Automatic Detection
Power: 14 W
Specifi cations*
* Specifications are subject to change without notice.
