NOMINAL CHARGE TIMES FOR NEXUS 50
Charge Level LED Indicators
100% Steady
Green
NEXUS 2, NEXUS 4 All Chem Chargers 25 minutes
Charge time can vary depending on age, condition and remaining capacity
of each battery at the time it is placed on the charger.
Phantom Battery Status Indications
• When the NEXUS phantom battery is being used, the LED
indicators will display status as listed below.
LEDS STATUS
GREEN Above 15.6 VDC
ORANGE Above 12.6 VDC
FLASHING RED Below 12.6 VDC
FLASHING RED Less than 30 minutes of charge
applied
• The Phantom battery will not be operational in the FLASHING
OR STEADY RED mode.
8
